Waste Radiator Recycling Plant (1000kgs/h)

The ETS Plants are designed for recycling car and truck tires for the production of clean rubber crumb and the separation of steel and textiles. Using normal temperature and non-chemical processing technology, these recycling systems are cost effective and don’t create secondary pollution. These plants are intended for customers who require an entry level, small scale tire recycling system with a capacity of 500-2,000kg/hr

Turn Waste Into Cash

2 拷贝

Plant Layout Drawing

3

4

The correct combination and sizing of the above listed equipment will provide a reliable, efficient tire recycling system that will produce a high quality rubber granulate, clean textile and steel ideal for sale, or for use in further processing equipment.

A typical High Performance Waste Radiator Recycling Line would include the following components

-Debeader – removal of the reinforcing steel wires from the tire rims

-Infeed Conveyor Belt – enables easy, controlled feeding of the tires

-Twin Shaft Shredder – shears the tires into strips

-Conveyor Belt – transports the tire shred to the Rasper

-Rasper – reduces the shred into 15-20mm chips and liberates remaining steel from the rubber

-Overbelt Magnet – separation of liberated steel from the rubber chips

-Conveyor Belt – transport the rubber chips

-Granulator – size reduction of the chips to 1-4mm granules and liberates the textile fraction to allow separation

-Vibratory Screen – sorts the granules by size and removes the majority of textile

-Zig-Zag Classifier – removal of remaining textile

-Drum magnet – removal of remaining steel fines

-Big-Bag Station
-Central De-dusting Unit – removes dust and fines from the system and filters
the air before returning it to atmosphere

-Control Panel
